Touchless Standing Drinking Fountain — 304/316 Stainless Steel Outdoor

Note： Due to contractual agreements, we are unable to sell or ship this product to any country within the European Union (EU), the United Kingdom (UK), or other European regions. Please contact support if you have questions.

How Sensor-Activated Hydration Works in Public Spaces

Public facility managers increasingly specify touchless drinking fountains because they eliminate the most common contamination pathway in shared hydration points — the push button. The PF20-363399 uses an infrared sensor that detects a user’s presence and activates the water stream automatically. When the user steps away, the solenoid valve closes immediately, preventing waste and limiting drip accumulation in the basin.

Sensor Range and Response Time

The activation zone is tuned for adult and child use, with a detection distance that accommodates wheelchair positioning without requiring the user to lean forward. Response time from detection to water flow is under one second, which keeps queues moving during peak periods at stadiums, trailheads, and school courtyards.

Power Options for Sites Without Mains Electricity

For remote installations such as rural parks or roadside rest areas, the unit can be configured for battery-powered or solar-supplemented operation. This flexibility makes the touchless drinking fountain viable where running a conduit to a junction box would be cost-prohibitive.

Material Selection: 304 vs 316 Grade for Outdoor Exposure

The body is fabricated from Type 304 stainless steel as standard, which handles most temperate and urban climates without issue. For coastal installations within salt-spray zones, or for projects in the Middle East and Southeast Asia where humidity and airborne chlorides are persistent, Type 316 is recommended. The molybdenum content in 316 substantially slows pitting corrosion on the bowl rim and spout collar — the two areas where water pooling occurs most frequently.

Surface Finish and Cleaning Cycles

A brushed satin finish is applied to the vertical surfaces to mask fingerprints and minor abrasion, while the bowl is polished to a smooth radius for fast wipe-down. Custodial teams can clean the unit with standard stainless steel cleaner and a microfiber cloth; no specialized tools are required for routine maintenance.

Structural Engineering for High-Traffic Durability

The cylindrical column design distributes lateral force evenly across the base plate, which matters when the fountain is installed in a skate park or outside a stadium gate where incidental contact and occasional impact are routine. The internal plumbing runs through the center of the column, protected by the outer shell, so there are no exposed pipes to grab or bend.

Anchoring and Anti-Tip Considerations

The base plate accepts four anchor bolts for concrete pad mounting. For installations on pavers or decking, a surface-mounted flange option is available. Engineering documentation including rough-in dimensions and anchor bolt patterns is provided for project submittals.

Project Applications Across Global Markets

Municipal procurement teams in North America, the European Union, ASEAN member states, and the Gulf region have different code requirements, but the underlying need is consistent: a hydration point that works reliably with minimal servicing. This touchless drinking fountain has been specified for urban renewal projects in Southeast Asia, university campus upgrades in the Middle East, and park district renovations across North America.

Transit and Transportation Hubs

Airport concourses and rail station platforms benefit from the cup-free configuration because passengers typically carry refillable bottles rather than disposable cups. The standing form factor also keeps the hydration point visible without obstructing sightlines to signage or platform edges.

Educational Campus Installations

School districts and university facilities departments value the touchless activation because it reduces absenteeism-linked illness transmission during cold and flu season. The standing height can be adjusted during fabrication to meet local accessibility codes for both adult and child reach ranges.

Customization for Distributor and Contractor Requirements

OEM and ODM customization is available for wholesalers and project procurement teams who need a differentiated product for their regional market. Options include powder-coating in RAL or Pantone-matched colors, laser-etched or screen-printed branding, alternate bubbler heights, and integrated bottle filler attachments.

Lead Times and MOQ for Project Bids

Standard production runs begin at a minimum order quantity of 5 units. Lead time for a standard configuration is typically 25–35 days from drawing approval, with expedited scheduling available for time-sensitive municipal contracts. Project-specific documentation including material certificates, NSF/ANSI 61 compliance data, and cUPC registration is supplied for submittal packages.

Compliance and Certification Documentation

Xinhe manufactures under ISO 9001 quality management systems, and this model carries CE marking for the European market. NSF/ANSI 61 certification applies to the water-contact components, confirming that the bubbler, valve, and internal tubing meet lead-free requirements for potable water dispensing.

Regional Code Alignment

For North American projects, the unit’s plumbing connections are compatible with standard 1/2-inch supply lines and 1-1/4-inch drain outlets, matching UPC and IPC rough-in conventions. For Australian and New Zealand installations, WaterMark certification documentation is available on request.

Company Profile

Built for Public Hydration Since 1990

Xinhe has been fabricating public drinking stations and commercial stainless steel products since 1990. We operate two factories totaling 52,000 square meters in Jiangmen, China and Ho Chi Minh City, Vietnam. Every unit is made to order in Type 304 or 316 stainless steel, with wall‑hung or standing configurations available.

Product Range

Full Line of Commercial Stainless Products

Beyond public drinking stations, Xinhe fabricates public sanitary ware, public drinking solutions, commercial kitchen equipment, accessibility facilities, sinks, and medical fixtures. All in 14 or 12-gauge stainless steel, with Type 304 standard and Type 316 available.

Professional Team

Serving North America, Europe & Australia

Xinhe’s sales team has worked with U.S., Canadian, European, and Australian buyers for over 20 years. We exhibit at KBIS, ISH Frankfurt, and AHR Expo annually. We understand municipal and commercial specifications and deliver on schedule.

Custom Touchless Drinking Fountain Manufacturer for Bulk and Project Orders

If you are sourcing a standing touchless drinking fountain, outdoor bottle filling station or custom stainless steel public water station for a public project, our team can support your requirements with flexible manufacturing solutions. We work with importers, wholesalers, contractors, project procurement teams and public facility suppliers looking for durable and customizable drinking fountain products.

Send us your project specifications, target dimensions, material requirements and quantity demand to receive a tailored quotation for your market or installation environment.
